MO-651 H3X
Remote Keyless Entry · CAN-based RKE receiver for 1-zone standard or extended access control.
MO-651 H3X is designed for door latch, trunk lid and lift-gate access control in mobile platforms. It combines code-rolling security and CAN communication for robust integration.
- Protocol
- CAN Bus (SAE J1939)
- Supply
- 12-24 VDC
- Protection
- IP54
Built for dedicated machine functions.
Highlights
- 1-zone standard or extended access logic
- Secure code transmission with rolling code technology
- CAN-based vehicle-level communication
- Built for mobile access automation
Specifications
- Communication
- CAN Bus (SAE J1939)
- Supply Voltage
- 12-24 VDC
- Ingress Protection
- IP54
- Housing
- % 30 GF Reinforced Polyamide Plastic Case
- Security
- Code rolling technology
- Application
- Door latches, trunk lids and lift gates
Drag to browse · click to enlarge
Build the order code from its segments
Pick one option from each column of the table and join them with dashes — the result is the code to quote when you order.
- MO 651
- H3X
- S1X
X stands for the digits you pick from the table.
| MO 651 - | H3X - Hardware | S1X Software |
|---|
* 1 zone control & CAN
** 1 zone control + 2 zone control with external relays & CAN
Example: 651.H30.S10 is standart type 1 zone control & CAN communication with SAE J1939 protocol
