MO-651 H4X
Remote Keyless Entry · CAN RKE module with 24-pin MOLEX interface for secure multi-zone access.
MO-651 H4X extends remote keyless entry integration with a 24-pin MOLEX connector and CAN-based architecture. It is engineered for reliable access control in demanding mobile environments.
- Protocol
- CAN Bus (SAE J1939)
- Supply
- 12-24 VDC
- Connector
- 24 Pin MOLEX 39012245
Built for dedicated machine functions.
Highlights
- 24-pin connector architecture for integration flexibility
- 1-zone standard or extended output variants
- Code rolling security against interception
- SAE J1939-ready CAN communication
Specifications
- Communication
- CAN Bus (SAE J1939)
- Supply Voltage
- 12-24 VDC
- Connector
- 24 Pin MOLEX 39012245
- Housing
- % 30 GF Reinforced Polyamide Plastic Case
- Security
- Code rolling technology
- Application
- Door latches, trunk lids and lift gates
Drag to browse · click to enlarge
Build the order code from its segments
Pick one option from each column of the table and join them with dashes — the result is the code to quote when you order.
- MO 651
- H4X
- S1X
X stands for the digits you pick from the table.
| MO 651 - | H4X - Hardware | S1X Software |
|---|
* 1 zone control & CAN
** 1 zone control + 2 zone control with external relays & CAN
Example: 651-H40 is Standart type 1 zone control & CAN communication with SAE J1939 protocol
