MO 651 H3X
Remote Keyless Entry — H3X · Wide-range CAN RKE control unit with up to 3-zone access
MO 651 H3X is a remote keyless entry control unit for doors, latches, trunk lids and lift gates, operating on an 8(12)–32V supply over a CAN (SAE J1939) bus, with code-rolling security and up to three-zone access control.
- Supply
- 8(12)–32V
- Bus
- CAN / J1939
- Zones
- Up to 3
Built for wide-range CAN remote keyless entry.
Highlights
- Wide 8(12)–32V supply range
- CAN / SAE J1939
- Code-rolling security
- Up to 3-zone access control
Specifications
- Type
- Remote keyless entry control unit
- Order code
- MO 651-H3X-S1X
- Supply voltage
- 8(12)–32V
- Bus
- CAN (SAE J1939)
- Zones
- 1 standard; up to 3 with external relays
- Security
- Code rolling
- Protection
- IP54
- Material
- 30% glass-fibre reinforced polyamide
Build the order code from its segments
Pick one option from each column of the table and join them with dashes — the result is the code to quote when you order.
- MO 651
- H3X
- S1X
X stands for the digits you pick from the table.
MO 651 - H3X - S1X |
|---|
| H30 - S10 - Supply 24 VDC Standard * |
| H31 - S10 - Supply 24 VDC Extended ** |
| H34 - S10 - Supply 12 VDC Standard * |
| H35 - S10 - Supply 12 VDC Extended ** |
* 1 zone control & CAN
** 1 zone control + 2 zone control with external relays & CAN
Example: 651.H30.S10 is standart type 1 zone control & CAN communication with SAE J1939 protocol
